CAMSO – UTV 4S1 Track System For Polaris RZR & General

Description

Will fit: 570cc RZR |2016-2020| *Without power steering* (6522-05-0570) 570cc RZR /Trail/EPS |2012-2015| (6522-05-0570) 570cc RZR EPS /Trail |2016-2020| *With power steering* (6522-05-0597) 570cc RZR S EPS |2017| (6522-05-0661) 800cc RZR /EPS/XC |2008-2014| (6522-05-0028) 800cc RZR 4 |2010-2014| (6522-05-0025) 800cc RZR S /HO/EPS |2009-2014| (6522-05-0025) 900cc RZR |2015-2016| *Without power steering*(M10 rear a-arm bolt) (6522-05-0925) 900cc RZR |2016,5-2020| *Without power steering*(M12 rear a-arm bolt) (6522-05-1358) 900cc RZR EPS /Trail/XC |2015-2016|*With power steering*(M10 rear a-arm bolt) (6522-05-0912) 900cc RZR EPS /Trail/XC/Premium |2016,5-2020|*With power steering*(M12 rear a-arm bolt)(6522-05-1333) 900cc RZR S |2015| *Without power steering*(M10 rear a-arm bolt) (6522-05-0950) 900cc RZR S |2015,5-2020| *Without power steering*(M12 rear a-arm bolt) (6522-05-0975) 900cc RZR S EPS |2015| *With power steering*(M10 rear a-arm bolt) (6522-05-0937) 900cc RZR S EPS /Premium |2015,5-2020| *With power steering*(M12 rear a-arm bolt) (6522-05-1290) 900cc RZR S4 EPS (4 seat) |2015-2018| (6522-05-1290) 1000cc General /General 4/EPS/Deluxe/Premium |2016-2020| (6522-05-1290) 1000cc RZR S EPS |2016-2020| (6522-05-1290) 1000cc RZR S4 EPS (4 seat) |2019-2020| (6522-05-1290) 900cc RZR XP /EPS/Jagged X |2011-2014| (6522-05-0900) 900cc RZR XP4 (4 seat) |2012-2014| (6522-05-0900) 1000cc RZR RS1 |2018-2019| (6522-05-1114) 1000cc RZR XP /EPS/Turbo |2014-2019|*Except Desert, Highlifter, Trail & Rock, Turbo S Edition*(6522-05-1114) 1000cc RZR XP4 EPS /Turbo/Dynamix/Ride Command (4 seat) |2014-2019| (6522-05-1114) This new track system reaches the next level of performance in any conditions. You simply won’t find another track kit offering this level of ride quality, performance, durability and ease of use. It’s the track system of choice for any applications including deep snow, swamps, marshes, mud, and muskeg.

• Maintains vehicle load capacity
• Engine-specific gearing for 400 cc and larger
• Interchangeable with over 99% of SxS brands and models
• Fast, easy swap from wheels to tracks and back again

Features:

• • Improved locking tensioner that increase strength, adjustment accuracy and serviceability.
  • Easier installation and improved vehicle adaptability
  • Easier adjustment with increased accuracy
  • Improved geometry adds durability in non-snow terrain and improves weight distribution
  • Internal drive, 15 to 18 teeth sprocket
  • Track width – Front: 12.5 inch Rear: 14 inch
  • Track length – Front: 98.5 inch Rear: 116.7 inch
  • System weight – Front: 103 lb Rear: 120 lb

• Triple bearing design with oil bath lubrication
  • Improved bearing durability Stainless sleeves for greater reliability

• SOLID STEEL FRAME
  • Open light-weight design
  • Improved durability and performance
  • Easily sheds snow, mud, and debris

• Rubber mount steel tandem, pivoting at each end
  • Rubber mount aluminium shaft axle, eliminates need for greasing; maintenance free
  • 132mm double bearing mid-roller wheels (width: 50mm)
  • 241mm double bearing flat free tires

• New anti-rotation bracket bolted onto the frame with factory pre-loaded spring and dual rubber damper (rear only)
  • Redesigned mild steel anti-rotation single-rate spring and progressive damper
  • Quick-connect steering limiter design
  • Maximize shock absorption to improve ride quality
• Easier to adjust the rod and the track to the required angle
  • More comfortable ride than traditional flat tracks
  • Improved frame suspension minimizes vibration, increases ride comfort, stability and overall durability
  • High-density tire with adjusted shape
  • Reduced friction and wear
  • Deliver trouble-free performance
• Oiled 3-bearing with forged steel multi-bolt (4-5) pattern hub
  • Enhanced wheel seal design
  • Bladder type wheel cap and face seal
  • Improved sealing, eliminating water absorption due to temperature variations
